OPT/IPL/E-Light Hair Removal Machine, Skin Rejuvenation and Lightening


Used around the world, the M22 enables you to treat more types of patients and conditions with better outcomes.4 Multiple Technologies In One Modular System.M22 grows with your practice and can expand to your treatment needs and adapts to future applications as they emerge.

– Acne Scar Treatment
– Hair Removal
– Non-Ablative Skin Resurfacing
– Photorejuvenation
– Pigmentation Treatment
– Scar Revision
– Vascular / Leg Vein Treatment

Universal IPL
Optimal Pulse Technology (OPT)
Single handpiece with changeable filters and lightguides
For IPL skin treatments using photorejuvenation

The only True fractional non-ablative, with CoolScan scanner
No disposables
For skin resurfacing

Universal IPL
Spectrum:515-1200 nm
ExpertFilters:515, 560, 590, 615, 640, 695, 755 nm
Fluence:10-35 J/cm2
Pulse Duration:4-20 ms
Pulse Delay:5-150 ms
Repetition Rate:Up to 1 Hz
Spot Size:35 x 15 mm2; 15 x 8 mm2
Cooling:Continuous contact cooling

Wavelength:1565 nm
Pulse Energy:10-70 mJ per micro-beam
Pulse Characteristic:CoolScanTM Scanner
Pattern Shapes:Line, square, rectangle, circle, donut, hexagon
Beam Density:Up to 500 micro-beams/cm2
Repetition Rate:0.5-2 Hz
Spot Size:Up to 18 mm
Cooling:Continuous contact cooling

System specifications
Dimensions:[without ResurFX] 44 x 50.5 x 47 cm (17 x 20 x 18.5 inches)
Dimensions:[with ResurFX] 44 x 50.5 x 61.5 cm (17 X 20 X 24 inches)
Weight:[without ResurFX] 40 kg / 88 lbs
Weight:[with ResurFX] 55 kg / 121 lbs
Electrical requirements:100  240 VAC ±10%, 15A max., 50/60 Hz, single phase, dedicated line

(1) IPL Handpiece*1
(2) Filters: 515nm, 560nm, 615nm, 640nm, 695nm
(3) Operator Eyewear*1
(4) Patient Eyewear*1
(5) Keys*1
(6) Electronic manual
(7) Calibration Unit


Product Name
IPL Pulsed Light Laser Machine
Intense pulsed light
Transfer System
Energy Density
Spot Size
8*40mm2/15*50mm2 (Optional)
Pulse Number
1-5 pulse (adjustable)
Pulse Width
5-30 ms (adjustable)
Pulse Delay
5-30 ms (adjustable)
Display Screen
8” TFT true color touchscreen
Cooling System
Water cooling, Air cooling, Semiconductor
-3℃ to 5℃
Electrical Source
